GD150LAB – GD150 Labyrinth Seal

The GD150LAB is a labyrinth seal designed for hydraulic and mechanical drive systems.
It provides effective protection against oil leakage and the ingress of dust or contaminants, significantly extending the service life of rotating components.
Manufactured from high-quality materials, it features a metal housing and a wear-resistant sealing lip capable of withstanding temperature fluctuations and pressure variations.

Technical Specifications:

• Model: GD150LAB

• Type: Labyrinth seal

• Inner diameter: 48 mm (example – may vary by version)

• Outer diameter: 62 mm

• Width: 7 mm

• Material: Steel housing with synthetic sealing element

• Function: Protection against leakage and contamination

• Applications: Hydraulic pumps, gearboxes, industrial shafts

• Temperature range: –30°C to +120°C

• Pressure capacity: Up to 10 bar (depending on installation)

Key Features:

• Non-contact sealing with minimal wear

• Protects shafts and bearings

• High resistance to heat and pressure

• Suitable for high-speed rotating systems
